DATA SHEET FOR 400 PVDF AODD PUMP
| Pump Model 400 PVDF AODD | |
|---|---|
| Quantity | 1 |
| Capacity | 230 LPM |
| Applications | Bromine, Highly Abrasive, High Temp., Filter Press Application |
| Air Pressure | 8.0 Bar |
| Liquid Inlet / Outlet | 1.5” |
| Air Inlet | ½” BSP |
| Make | “NIRMALA” Make |
| Type | Air Operated Diaphragm Pump |
| Suction Size | 1.5” |
| Discharge Size | 1.5” |
| Connection | Flange End as per ASA-150 |
| Diaphragm | PTFE Diaphragm with Santoprene Backup |
| NRV Ball | PTFE |
| Pump Model 400 PVDF AODD | |
|---|---|
| Wetted Parts | PVDF |
| Outer Piston | PVDF |
| Centre Piston (Holding Plate) | MS Powder Coated |
| Air Valve Assembly | Polypropylene |
| Diaphragm | PTFE Diaphragm with Sentoprene Backup |
| Valve Ball | PTFE |
| Valve Seat | PVDF |
| O Ring | PTFE |
| Pump Model 400 PVDF AODD | |
|---|---|
| Suction Lift (Dry) | 3.05 Mtr (10’) |
| Suction Lift (Wet) | 6.09 Mtr (20’) |
| Maximum Flow Rate | 210 LPM |
| Maximum Size Solids | 4.76 mm (1.188”) |
| Maximum Air Pressure | 8 bar |
| Air Inlet | ½” BSP |
| Liquid Inlet | 38.10 mm (1.5”) |
| Liquid Outlet | 38.10 mm (1.5”) |
| Air Pressure (KG/CM²) | Head (Meter) | CFM | Capacity (LT/MN) | M³/HR |
| 1 | Open | 12 | 101.53 | 6.09 |
| 2 | Open | 15 | 157.14 | 9.43 |
| 10 | 14 | 117.85 | 7.07 | |
| 3 | Open | 18 | 189.00 | 11.31 |
| 10 | 18 | 155.00 | 9.21 | |
| 20 | 18 | 110.00 | 6.60 | |
| 4 | Open | 22 | 200.00 | 12.00 |
| 10 | 21 | 183.50 | 11.00 | |
| 20 | 23 | 137.50 | 8.25 | |
| 30 | 22 | 107.00 | 6.39 | |
| 5 | Open | 25 | 228.00 | 13.65 |
| 10 | 24 | 206.25 | 12.38 | |
| 20 | 23 | 165.00 | 9.90 | |
| 30 | 23 | 136.00 | 8.08 | |
| 40 | 23 | 92.00 | 5.50 |
| Pump Model 400-PVDF-AODD | |
|---|---|
| P.P | 0˚C – 80˚C |
| PVDF | -12˚C – 110˚C |
| Neoprene | -17˚C – 110˚C |
| Viton | -40˚C – 176˚C |
| Teflon | 4.4˚C – 220˚C |
Get Reliable Flow With Our
400 PVDF AODD Pump
Dealing with harsh chemicals or abrasive liquids is never easy, but the 400 PVDF AODD Pump from Nirmala Pumps makes the job much smoother. This pump is a standout in our PVDF AODD Pumps lineup, specifically built for those who can’t afford downtime caused by corrosion or leaks. The pump is built for industries that deal with harsh and corrosive chemicals. This 1 ½ inch PVDF AODD pump is widely used in chemical plants, pharmaceuticals, water treatment, and processing units.
Our 1 ½″ PVDF AODD pump is valued for its strong build, smooth operation, and reliable performance in demanding conditions. We are counted among reliable 1 ½-inch PVDF AODD Pump manufacturers in India, offering cost-effective pumping solutions with consistent support.
As top 1 ½-inch PVDF AODD Pump suppliers in India, we have built our reputation on quality that lasts. If you’re struggling with pumps that leak or corrode when handling harsh acids, our 400 PVDF AODD Pump is going to be a game-changer for you.
