DATA SHEET FOR 300 PVDF AODD PUMP
| Pump Model 300 PVDF AODD | |
|---|---|
| Quantity | 1 |
| Max. Capacity | 105 LPM |
| Applications | Bromine, High Temperature Abrasives Application |
| Liquid Inlet / Outlet | 1” |
| Air Pressure | 8 – 8.6 bar |
| Air Inlet | ¼” (6.35 mm) |
| Make | “NIRMALA” Make |
| Type | Air Operated Diaphragm Pump |
| Suction Size | 1” |
| Discharge Size | 1” |
| Flange Connection | BSP Threaded / Flange as per ASA-150 |
| Diaphragm | PTFE Diaphragm |
| NRV Ball | PTFE Ball |
| Pump Weight | 9.5 Kg |
| Pump Model 300 PVDF AODD | |
|---|---|
| Wetted Parts | PVDF |
| Outer Piston | PVDF |
| Centre Piston | MS Epoxy Coated |
| Air Valve (Non-Wetted Parts) | PP |
| Diaphragm | PTFE Diaphragm with Santoprene Backup |
| Valve Ball | PTFE |
| Valve Seat | PVDF |
| O Ring | PTFE |
| Pump Model 300 PVDF AODD | |
|---|---|
| Suction Lift (Dry) | 3.05 mtr (10’) |
| Suction Lift (Wet) | 4.89 mtr (16’) |
| Maximum Flow Rate | 105 LPM |
| Maximum Size Solids | 3.17 mm (0.125”) |
| Maximum Air Pressure | 8.06 bar |
| Air Inlet | 9.53 mm (3/8”) |
| Liquid Inlet | 25.40 mm (1”) |
| Liquid Outlet | 25.40 mm (1”) |
| Air Pressure (KG/CM²) | Head (Meter) | CFM | Capacity (LT/MN) | M³/HR |
| 2 | Open | 8 | 55 | 3.30 |
| 10 | 8.5 | 34 | 2.04 | |
| 3 | Open | 15 | 71 | 4.26 |
| 10 | 14 | 50 | 3.00 | |
| 20 | 18 | 38 | 2.28 | |
| 4 | Open | 14 | 86 | 5.16 |
| 10 | 17 | 66 | 3.96 | |
| 20 | 25 | 54 | 3.30 | |
| 30 | 23 | 47 | 2.58 | |
| 6 | Open | 17 | 103 | 6.06 |
| 10 | 15 | 89 | 5.34 | |
| 20 | 19 | 71 | 4.26 | |
| 30 | 20 | 59 | 3.54 | |
| 40 | 23 | 44 | 2.64 |
| Pump Model 300-PVDF-AODD | |
|---|---|
| P.P | 0˚C – 80˚C |
| PVDF | -12˚C – 110˚C |
| Neoprene | -17˚C – 110˚C |
| Viton | -40˚C – 176˚C |
| Teflon | 4.4˚C – 220˚C |
Get Reliable Flow With Our
300 PVDF AODD Pump
Dealing with harsh chemicals or abrasive liquids is never easy, but the 300 PVDF AODD Pump from Nirmala Pumps makes the job much smoother. This pump is a standout in our PVDF AODD Pumps lineup, specifically built for those who can’t afford downtime caused by corrosion or leaks. The pump is built for industries that deal with harsh and corrosive chemicals. This 1-inch PVDF AODD pump is widely used in chemical plants, pharmaceuticals, water treatment, and processing units.
Our 1″ PVDF AODD pump is valued for its strong build, smooth operation, and reliable performance in demanding conditions. We are counted among reliable 1-inch PVDF AODD Pump manufacturers in India, offering cost-effective pumping solutions with consistent support.
As top 1-inch PVDF AODD Pump suppliers in India, we have built our reputation on quality that lasts. If you’re struggling with pumps that leak or corrode when handling harsh acids, our 150 PVDF AODD Pump is going to be a game-changer for you.
