PPH True Union Ball Valve





Union Type Ball Valve PPH
PPH True Union Ball Valve
| PPH True Union Ball Valve Specifications | |
|---|---|
| Material (Body & Ball) | PPH (Polypropylene Homopolymer) |
| End Connection | Socket / Threaded / Flanged (As per requirement) |
| Size Range | ½” to 2” (15 mm to 50 mm) |
| Working Pressure | Up to 10 Bar (PN10) |
| Temperature Range | -10°C to +90°C |
| Seal Material | EPDM / FPM (Viton) |
| Seat Material | PTFE |
| Operation | Manual (Lever Type) / Optional Pneumatic or Electric Actuator |
| Union Type | Double Union for Easy Maintenance |
| Color | Light Grey |
- Double union design for easy installation & removal
- Full bore for maximum flow
- Chemical corrosion resistant PPH construction
- Maintenance-friendly design with replaceable seats and seals
- Leak-proof performance with PTFE seats
- Smooth lever operation
- Chemical Process Plants
- Water Treatment & RO Plants
- Acid Handling Systems
- Industrial Piping Lines
- Laboratories Research Facilities

Simplify Your Pipe Repairs with the PPH True Union Ball Valve
If you are tired of cutting pipes every time a valve needs a repair, our PPH True Union Ball Valve is exactly what you need. The ” True Union” design means you can easily unscrew the nuts and take the valve body out without moving the rest of your pipeline. You can clean it or check it in minutes without messing up your whole pipeline.
As one of the top PPH true union ball valve manufacturers in India, we build these using high-quality PPH because it handles heat and chemicals way better than basic plastic. We’ve kept the features practical—like a handle that actually turns smoothly and a tight seal that won’t let you down. It’s the same reliable quality you’d expect from the big names, but with the personal service we’re known for. If you’re looking for a partner who delivers on time, we are top-rated PPH True Union Ball Valve suppliers in India.
